Technique

• Tension nominale (Ur):

  acc. To IEC 400 V


• Tension:

  400 V AC


• Tension assignée d’isolement (Ui):

  1 kV


• Fréquence assignée (f):

  50/60 Hz


• Power Loss:

  at Rated Operating Conditions per Pole 3 W


• Nombre de pôles:

  4


• Number of Protected Poles:

  3


• Position of Neutral Terminals:

  Left


• Couple de serrage:

  0.8...1.2 N·m


• Type de fusible:

  gG and aM cylindrical fuse links


• Lock Type:

  Padlockable


• Type de montage:

  DIN-Rail


• Type d'étanchéité:

  Sealing Wire


• Material of Conductor:

  Copper


• Options Provided:

  No


• Recommended Screw Driver:

  Pozidriv 2


• Shock and Vibration Withstand acc. to IEC 61373:

  Category 1, Class B


• Connecting Capacity:

  Stranded 1.5…10 mm²
  Rigid 1.5…16 mm²


• Taille de fusible:

  10x38 mm


• Operating Humidity (RHamb):

  max. 90% at +20 °C, 50% at max. +40 °C


• Rated Operational Current AC (Ie):

  32 A
