Technique

• Normes et standards:

  IEC/EN 61008


• Type of Residual Current:

  AC type


• Tension nominale (Ur):

  230/400 V


• Tension:

  230 / 400 V AC


• Tension assignée d’isolement (Ui):

  500 V


• Tension assignée de tenue aux chocs (Uimp):

  4 kV


• Courant nominal (In):

  63 A


• Rated Residual Current:

  300 mA


• Pourvoir assigné de coupure de service en court-circuit (Ics):

  1 kA


• Maximum Surge Current:

  0.25 kA


• Leakage Current Type:

  AC


• Fréquence assignée (f):

  50 Hz


• Power Loss:

  at Rated Operating Conditions per Pole 4.4 W


• Nombre de pôles:

  4


• Operating Characteristic:

  Instantaneous


• Position of Neutral Terminals:

  Right


• Type de montage:

  DIN-Rail


• Options Provided:

  None


• Accessories Available:

  Non


• Section nominale:

  4 - Multi-Wired 10...25 mm²
  1 - Solid-Core 25...25 mm²
