Technique

Normes et standards:IEC/EN 61008

Type of Residual Current:AC type

Tension nominale (Ur):230/400 V

Tension:230 / 400 V AC

Tension assignée d’isolement (Ui):500 V

Tension assignée de tenue aux chocs (Uimp):4 kV

Courant nominal (In):40 A

Rated Residual Current:300 mA

Pourvoir assigné de coupure de service en court-circuit (Ics):1 kA

Maximum Surge Current:0.25 kA

Leakage Current Type:AC

Fréquence assignée (f):50 Hz

Power Loss:at Rated Operating Conditions per Pole 3.2 W

Nombre de pôles:4

Operating Characteristic:Instantaneous

Position of Neutral Terminals:Right

Type de montage:DIN-Rail

Options Provided:None

Accessories Available:Non

Section nominale:4 - Multi-Wired 10...25 mm²

1 - Solid-Core 25...25 mm²
