Technique
Normes et standards:IEC/EN 60898-1
Tripping Characteristic:C
Tension:acc. to IEC 60898-1 400 V AC
Operational Voltage:Maximum (Incl. Tolerance) 440 V AC
Minimum 12 V AC
Tension assignée d’isolement (Ui):acc. to IEC/EN 60664-1 440 V
Tension assignée de tenue aux chocs (Uimp):4 kV
at 2000 m 5 kV
at Sea Level 6.2 kV
Dielectric Test Voltage:50/60 Hz, 1 min: 2 kV
Type de tension:AC
Courant nominal (In):32 A
Rated Short-Circuit Capacity:(AC) 4.5 kA
(400 V AC) 4.5 kA
Rated Conditional Short-Circuit Current (Inc):(400 V) 5 kA
Fréquence assignée (f):50 / 60 Hz
Power Loss:7.4 W
at Rated Operating Conditions per Pole 3.7 W
Power Supply Connection:Arbitrary
Contact Position Indication:ON / OFF
Classe de limitation d'énergie:3
Electrical Endurance:10000 AC cycle
Mechanical Endurance:20000 cycle
Nombre de pôles:2
Number of Protected Poles:2
Catégorie de Surtension:III
Couple de serrage:2 N·m
Actuator Type:Toggle
Screw Terminal Type:Cage Terminal
Actuator Marking:I / O
Actuator Material:Insulation Group II, Black, Sealable
Qualité du matériau:Insulation Group II, RAL 7035
Montage sur rail DIN:TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Type d'encastrement:any
Recommended Screw Driver:Pozidriv 2
Accessories Available:Non
Connecting Capacity:Conductor 25 / 25 mm²
Flexible with Ferrule 0.75 ... 16 mm²
Flexible 0.75 ... 16 mm²
Rigid 0.75 ... 25 mm²
Stranded 0.75 ... 25 mm²
Installation Size:acc. to DIN 43880 1
Type de borne:Screw Terminals
