Technique

Normes et standards:IEC/EN 60898-1

Tripping Characteristic:C

Tension:acc. to IEC 60898-1 230 / 400 V AC

Operational Voltage:Maximum (Incl. Tolerance) 253 V AC

Minimum 12 V AC

Tension assignée d’isolement (Ui):acc. to IEC/EN 60664-1 440 V

Tension assignée de tenue aux chocs (Uimp):4 kV

at 2000 m 5 kV

at Sea Level 6.2 kV

Dielectric Test Voltage:50/60 Hz, 1 min: 2 kV

Type de tension:AC

Courant nominal (In):25 A

Rated Short-Circuit Capacity:(AC) 3 kA

(230 / 400 V AC) 3 kA

Rated Conditional Short-Circuit Current (Inc):(230 V) 3 kA

(400 V) 3 kA

Fréquence assignée (f):50 / 60 Hz
