Technical

Standards:IEC/EN 60898-1

CSA 22.2 No. 235

IEC/EN 60947-2

UL 1077

Tripping Characteristic:C

Rated Operational Voltage:acc. to IEC 60898-1 400 V AC

acc. to IEC 60947-2 440 V AC

Operational Voltage:Maximum (Incl. Tolerance) 440 V AC

Minimum 12 V AC

Minimum 12 V DC

Rated Insulation Voltage (Ui):acc. to IEC/EN 60664-1 440 V

Rated Impulse Withstand Voltage (Uimp):4 kV

at 2000 m 5 kV

at Sea Level 6.2 kV

Dielectric Test Voltage:50/60 Hz, 1 min: 2 kV

Input Voltage Type:AC/DC

Rated Current (In):25 A

Rated Short-Circuit Capacity:(AC) 10 kA

(230 V AC) 10 kA

(400 V AC) 10 kA

Rated Ultimate Short-Circuit Breaking Capacity (Icu):(230 V AC) 25 kA

(400 V AC) 15 kA

(440 V AC) 15 kA

Rated Conditional Short-Circuit Current (Inc):(230 V) 15 kA

(400 V) 25 kA

Rated Service Short-Circuit Breaking Capacity (Ics):(230 V AC) 7.5 kA

Frequency (f):50 Hz

Rated Frequency (f):50 / 60 Hz

Power Loss:9.6 W

at Rated Operating Conditions per Pole 3.2 W

Power Supply Connection:Arbitrary

Contact Position Indication:Red ON / Green OFF

Energy Limiting Class:3

Electrical Endurance:20000 AC cycle

Mechanical Endurance:20000 cycle

Number of Poles:3

Number of Protected Poles:3

Overvoltage Category:III

Tightening Torque:2.8 N·m

Screw Terminal Type:Failsafe Bi-directional Cylinder-lift Terminal

Actuator Marking:I / O

Actuator Material:Insulation Group II, Black, Sealable

Housing Material:Insulation Group II, RAL 7035

Mounting on DIN Rail:TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715

TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715

Mounting Position:any

Recommended Screw Driver:Pozidriv 2

Accessories Available:Yes

Connecting Capacity:Busbar 10 / 10 mm²

Flexible with Ferrule 0.75 ... 25 mm²

Flexible 0.75 ... 25 mm²

Rigid 0.75 ... 35 mm²

Stranded 0.75 ... 35 mm²

Installation Size:acc. to DIN 43880 1

Terminal Type:Screw Terminals
