Technique

Normes et standards:IEC 61009-1

IEC 61009-2-1

EN 61009-1

EN 61009-2-1

Tripping Characteristic:C

Type of Residual Current:AC type

Tension nominale (Ur):230-240 V AC

Tension:230 / 240 V AC

Tension assignée d’isolement (Ui):500 V

Tension assignée de tenue aux chocs (Uimp):4 kV

Type de tension:AC

Courant nominal (In):25 A

Rated Residual Current:300 mA

Rated Short-Circuit Capacity:4.5 kA

Pouvoir assigné de coupure ultime en court-circuit (Icu):6 kA

Rated Conditional Short-Circuit Current (Inc):6 kA

Rated Service Short-Circuit Breaking Capacity, in % of Icu (Ics):4.5 kA

Maximum Surge Current:0.25 kA

Leakage Current Type:AC

Fréquence (f):50/60 Hz

Fréquence assignée (f):50 … 60 Hz

Power Loss:3.9 W

Power Supply Connection:Arbitrary

Classe de limitation d'énergie:3

Electrical Endurance:10000 cycle

Mechanical Endurance:20000 cycle

Nombre de pôles:1+N

Number of Protected Poles:1

Operating Characteristic:Instantaneous

Catégorie de Surtension:III

Position of Neutral Terminals:Left

Earthing Switch Type:Undelayed

Type de libération:C

Options Provided:None

Accessories Available:Oui

Connecting Capacity:Busbar 10 mm²

Rigid 25 ... 25 mm²

Flexible 25 ... 25 mm²

Section nominale:4 - Multi-Wired 1...16 mm²

1 - Solid-Core 25...25 mm²
