Technique

• Normes et standards:

  IEC 61009-1
  IEC 61009-2-1
  EN 61009-1
  EN 61009-2-1


• Tripping Characteristic:

  C


• Type of Residual Current:

  AC type


• Tension nominale (Ur):

  230-240 V AC


• Tension:

  230 / 240 V AC


• Tension assignée d’isolement (Ui):

  500 V


• Tension assignée de tenue aux chocs (Uimp):

  4 kV


• Type de tension:

  AC


• Courant nominal (In):

  10 A


• Rated Residual Current:

  300 mA


• Rated Short-Circuit Capacity:

  4.5 kA


• Pouvoir assigné de coupure ultime en court-circuit (Icu):

  6 kA


• Rated Conditional Short-Circuit Current (Inc):

  6 kA


• Rated Service Short-Circuit Breaking Capacity, in % of Icu (Ics):

  4.5 kA


• Maximum Surge Current:

  0.25 kA


• Leakage Current Type:

  AC


• Fréquence (f):

  50/60 Hz


• Fréquence assignée (f):

  50 … 60 Hz


• Power Loss:

  2.3 W


• Power Supply Connection:

  Arbitrary


• Classe de limitation d'énergie:

  3


• Electrical Endurance:

  10000 cycle


• Mechanical Endurance:

  20000 cycle


• Nombre de pôles:

  1+N


• Number of Protected Poles:

  1


• Operating Characteristic:

  Instantaneous


• Catégorie de Surtension:

  III


• Position of Neutral Terminals:

  Left


• Earthing Switch Type:

  Undelayed


• Type de libération:

  C


• Options Provided:

  None


• Accessories Available:

  Oui


• Connecting Capacity:

  Busbar 10 mm²
  Rigid 25 ... 25 mm²
  Flexible 25 ... 25 mm²


• Section nominale:

  4 - Multi-Wired 1...16 mm²
  1 - Solid-Core 25...25 mm²
