Technical

• Standards:

  IEC/EN 61009 Ann. G


• Type of Residual Current:

  AC type


• Rated Voltage (Ur):

  230/400 V


• Rated Operational Voltage:

  230/400 V


• Rated Insulation Voltage (Ui):

  500 V


• Rated Impulse Withstand Voltage (Uimp):

  4 kV


• Rated Current (In):

  63 A


• Rated Residual Current:

  300 mA


• Leakage Current Type:

  AC


• Rated Frequency (f):

  50 … 60 Hz


• Power Loss:

  7.6 W


• Power Supply Connection:

  Arbitrary


• Electrical Endurance:

  10000 cycle


• Number of Poles:

  4


• Operating Characteristic:

  Instantaneous


• Options Provided:

  -


• Connecting Capacity:

  Rigid 25 ... 25 mm²
  Flexible 25 ... 25 mm²
