Technique

• Normes et standards:

  IEC EN 60947-2 Ann. B


• Type of Residual Current:

  A type


• Adapté pour:

  S800S
  S800N
  S800C
  S800B


• Tension nominale (Ur):

  230/400 V AC
  240/415 V AC
  400/690 V AC


• Tension:

  400/690 V


• Tension assignée d’isolement (Ui):

  690 V


• Tension assignée de tenue aux chocs (Uimp):

  6 kV


• Courant nominal (In):

  63 A


• Rated Residual Current:

  300 mA


• Maximum Surge Current:

  5 kA


• Leakage Current Type:

  A


• Fréquence assignée (f):

  50 … 60 Hz


• Power Loss:

  13.5 W


• Nombre de pôles:

  4


• Operating Characteristic:

  Selective


• Options Provided:

  -


• Connecting Capacity:

  Rigid 6 … 50 mm²
  Flexible 6 … 70 mm
