Technique

• Normes et standards:

  IEC/EN 61009 Ann. G


• Type of Residual Current:

  A type


• Tension nominale (Ur):

  230/400 V


• Tension:

  230/400 V


• Tension assignée d’isolement (Ui):

  500 V


• Tension assignée de tenue aux chocs (Uimp):

  4 kV


• Courant nominal (In):

  40 A


• Rated Residual Current:

  300 mA


• Leakage Current Type:

  A


• Fréquence assignée (f):

  50 … 60 Hz


• Power Loss:

  4.8 W


• Power Supply Connection:

  Arbitrary


• Electrical Endurance:

  10000 cycle


• Nombre de pôles:

  3


• Operating Characteristic:

  Instantaneous


• Options Provided:

  -


• Connecting Capacity:

  Rigid 16 ... 16 mm²
  Flexible 16 ... 16 mm²
